| Brand Name: | Welons |
| Model Number: | Custom |
| MOQ: | 100 pcs |
| Price: | USD 30-300 /pcs |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pcs per year |
1500W-12V HYBRID INVERTER
Detail
| DATASHEET | 8KW 10.2KW 12KW |
| RATED POWER | 8000W 10200W 12000W |
| INPUT | |
| Voltage | 230 VAC |
| Selectable Voltage Range | 170-280 VAC(For Personal Computers)90-280 VAC(For Home Appliances) |
| MPPT Tracker Number | 2 |
| Maximum input current of PV | 27 A*2(Max 40A) |
| Frequency Range | 50 Hz/60 Hz(Auto sensing) |
| OUTPUT | |
| AC Voltage Regulation(Batt.Mode) | 230VAC±5% |
| Surge Power | 16000VA 20400VA 24000VA |
| Efficiency(Peak)PVto INV | 97% |
| Efficiency(Peak)Battery to INV | 94% |
| Transfer Time | 10 ms(For Personal Computers);20 ms(For Home Appliances) |
| Output Port | Dual output(Optional) |
| Waveform | Pure sine wave |
| BATTERY &AC CHARGER | |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54VDC |
| Overcharge Protection | 61VDC |
| Maximum Charge Current | 160 A(From grid) |
| SOC display | Shows battery State of charge in percentage and in voltage as well |
| Sleeping Mode | YES |
| Battery voltage low cut off selectable | 40V-49V |
| Battery High voltage range selectable | 50V-60V |
| Works without Battery | YES |
| SOLAR CHARGER | |
| Maximum PVArray Power | 10000W 12000W 13000W |
| MPPTRange @Operating Voltage | 60-450 VDC |
| Maximum PVArray Open Circuit Voltage | 500 VDC |
| Municipal electricity | 160A |
| Maximum Efficiency | 98% |
| PHYSICAL | |
| Dimension,D×W×H(mm) | 128*300*363 |
| Net Weight(kgs) | 16.5 18 19 |
| Communication interface | USB/RS232/RS485/WIFI(Optional) |
| LCD display | General LCD |
| OPERATING ENVIRONMENT | |
| Humidity | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | 0°C - 55°C |
| Storage Temperature | -15℃-60℃ |
| Waterproof grade | IP21 |
