| Model Number: | Custom |
| MOQ: | 100 pcs |
| Price: | USD 30-300 /pcs |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pcs per year |
The LR5-72HPH series PVT solar module combines power generation and thermal heating in a single design, delivering dual benefits of electricity and hot water from sunlight. Featuring durable construction and reliable outdoor performance, it is ideal for residential and commercial renewable energy systems requiring combined power and heating solutions.
| Product Type | PVT Photovoltaic-Thermal Solar Module |
| Model Series | LR5-72HPH |
| Overall Dimensions | 2278 * 1134 * 35 mm |
| Unit Weight | 35~42 kg |
| Front Glass | 3.2mm Single Tempered Glass |
| Frame | Anodized Aluminum Alloy |
| Junction Box | Split type, IP68 rated |
| Output Cable | 4mm², customizable length |
| Operating Temperature Range | -40℃ ~ +85℃ |
| Front Static Load Resistance | 5400 Pa |
| Back Static Load Resistance | 2400 Pa |
| Hail Impact Resistance | Withstands 25mm diameter hail at 23m/s impact speed |
| Safety Rating | Class II |
| Compliance Standards | IEC/UL certified |
