Solar PV Glass
Created with Pixso.

2279mm Monocrystalline Solar Photovoltaic Panels For Residential Commercial

2279mm Monocrystalline Solar Photovoltaic Panels For Residential Commercial

Brand Name: welons
Model Number: Custom
MOQ: 100 pcs
Price: USD 30-300 /pcs
Payment Terms: T/T
Supply Ability: 500000 pcs per year
Detail Information
Place of Origin:
China
Certification:
CE ROHS FCC
Maximum Power:
550W
Module Dimension:
2279×1134×30mm
Weight:
27KG ±3%
Operating Temperature:
-40°C ~ +85°C
Packaging Details:
1.2mX2.4m wooden Case packaging
Highlight:

2279mm solar photovoltaic panels

,

Monocrystalline solar photovoltaic panels

,

Commercial waterproof solar panel

Product Description
550W Solar panel Solar power generation panel Photovoltaic solar panel Monocrystalline component High conversion rate

This monocrystalline PV module delivers stable, high-yield power generation for residential, commercial, and industrial solar systems. Built with premium Grade A mono solar cells and advanced encapsulation technology, it ensures long service life, excellent weather resistance, and reliable performance even in low-light environments.

Parameter Details
Cell Type Monocrystalline (182mm Multi-Busbar)
Module Dimension 2279*1134*30mm
Weight 27KG ±3%
Structure 3.2mm High-Transmittance AR Coated Tempered Glass + EVA Film + White Backsheet
Frame Anodized Aluminum Alloy
Junction Box 3-part, IP68 Protection Rating
Cable 4.0mm², (+) 280mm / (-) 280mm (Customizable)
Connector Original MC4 / MC4 Compatible
Mechanical Load Front 5400Pa / Rear 2400Pa (Static Pressure)
Key Features
  • High Power Output: 550W rated power with efficient energy conversion rate up 23.5%.
  • Premium Grade A Mono Cells: Low attenuation, high stability, long lifespan.
  • Half-Cut Design: Better anti-shading performance, higher reliability.
  • Durable Construction: Tempered glass, aluminum frame, wind and snow load resistant.
  • IP68 Waterproof & Dustproof: Suitable for outdoor harsh environments.
  • IEC & CE Certified: Safe, reliable, and compatible with global standards.
  • 25-Year Linear Power Warranty: Stable output and long-term investment protection.
Applications
  • Residential rooftop solar systems
  • Commercial & industrial rooftop PV
  • Solar power stations
  • Off-grid and hybrid solar systems
  • Agricultural PV, carports, and BIPV projects
Specifications (General)
  • Maximum Power (Pmax): 550W
  • Cell Type: Monocrystalline
  • Panel Type: Half-cut mono
  • Glass: 3.2mm high-transmittance tempered glass
  • Frame: Anodized aluminum alloy
  • Operating Temperature: -40°C ~ +85°C
  • Warranty: 25-year performance warranty
